When the photo-port is switched open, all light from the left objective is diverted to the port to provide maximum brightness for the camera to guarantee the best quality images. The switched trinocular photo-port provides a dedicated mount for a camera. Sliding interpupillary adjusters ensure that each user can properly align the eyepieces for comfortable viewing. Magnifications and Working-Distancesĭual ocular diopters can be adjusted to maintain consistent focus, greatly improving productivity. 10X and 25X eyepieces are included, as well as 0.3X and 2X Barlow lenses to provide an expanded magnification range from 2X-225X, with high-eyepoint optics to accommodate glasses or goggles.

boom 3d microscope boom 3d microscope

The 0.67X-4.5X objective lenses offer excellent focus-depth and a large working-distance, with symmetrical zoom knobs to easily move through magnifications.

#BOOM 3D MICROSCOPE SERIES#

The advanced optical system in the ZM series microscope produces higher resolutions throughout its zoom range, with stunning contrast and color accuracy. With its wide zoom range and double-arm boom-stand, this model will become an indispensable instrument in any workshop or lab. This trinocular model has an additional port for mounting a camera, so you can record video or photos without replacing an eyepiece. This model is especially popular in the QC, repair and engraving industries thanks to its ease-of-use and reliability. The ZM series shows improvements in resolution, contrast, and distortion compared to our staple SM series. The ZM-4T matches high-resolution optics with a brawny boom-stand for demanding biological and industrial applications. CALIBRATION SLIDES & STAGE MICROMETERS | SUBCATEGORY.BOOKS & EXPERIMENTS CARDS | SUBCATEGORY.SPZ Binocular Stereo Zoom Microscope Body 2 ea. Optional 15x(FN15) and 20x(FN11.4) available to extend magnification rangeĠ.5x, 0.75x, 1.6x and 2x auxiliary lenses available to extended magnification range of microscopeġ08mm without auxiliary lens 240mm with 0.5x auxiliary lens 132mm with 0.75x auxiliary lens 50mm with 1.6x auxiliary lens 41mm with 2x auxiliary lensġ ea. Two 10x(FN23)eyepieces supplied with microscope body. 26200A-310 - Fiber Optic Illuminator 24Wīinocular, 360° rotatable, 45° inclined eyepiece tube.Specs Ultra-Glide Boom Stand System with SPZ-50 Stereo Zoom Microscope and LED E-Arm Focus Mount The 26200A-310 contains a 24 watt LED lamp, outputs a color temperature of 5600K, and has an expected lamp life of 10,000 hours.

boom 3d microscope

Users can choose from single and dual pipe guides, as well as annular ring lights and much more. A versatile illumination source, this device easily adapts to your specific application.

  • Heavy 15 x 10.5 inch base assures stability and spaceĪven’s 26200A-310 Fiber Optic Illuminator is compatible with most fiber optic cables and guides.
  • Allows positioning of microscopes over large area.
  • 23 inch gliding arm provides smooth horizontal movement.
  • A heavy metal base provides excellent stability and a safety collar on the support post provides added protection for your inspection system. Features two locking knobs to adjust the horizontal and vertical position of the gliding arm.

    boom 3d microscope

    Ultra-Glide Boom Stand Smooth Gliding Motion Smooth motion of the gliding arm allows the microscope to easily scan across the subject. Diopter adjustment on both eyepiece tubes.17mm (0.67") high eye point wide field 10x eyepieces (field number 23) for comfortable viewing even for operators with eyeglasses.Working distance 108mm (4.25") – the best in class.Large zoom ratio 7.46:1- best zoom ratio in class.SPZ-50 Stereo Zoom Microscope Wide Magnification Range Aven’s SPZ-50 Stereo Zoom Microscope has a magnification range of 6.7x-50x, which can be enhanced to up to 200x with optional auxiliary lenses and eyepieces. These components make this system an ideal choice for high throughput inspection stations and engineering and science labs. This microscope offers the best in class zoom ratio (7.46:1) with super sharp 3D images, wide field of view (1.35" to 0.14") and long working distance (4.25"). This system features Aven's SPZ-50 Stereo Zoom Microscope. The stand features a 13.5 inch post with a safety collar, and a heavy 10.5 x 15 inch base. The ultra-glide boom stand provides smooth motion along it's 23" arm, allowing for easy scanning. SPZ-50 Stereo Zoom Binocular Microscope with Ultra Glide Stand and FOI LED Illumination Magnification range: 6.7x-50x Aven's Ultra-Glide Boom Stand System is ideal for inspecting parts over a large surface area.
